Force/Torque Indicators
with Remote Sensors

Home » Force/Torque Indicators with Remote Sensors



Model 3i, Model 3i – Basic Force/Torque Indicator

The 3i digital force/torque indicator is designed to work with a wide range of remote force and torque sensors. With exclusive Plug & Test (TM) technology, all calibration and configuration data is saved within the sensor’s smart connector, not the indicator, allowing for true interchangeability. In addition, all sensors are fully compatible with the advanced 5i force/torque indicator.

Model 5i, Model 5i – Advanced Force/Torque Indicator

The 5i advanced digital force/torque indicator is designed to work with a wide range of remote foce and torque sensors. With exclusive Plug & Test (TM) technology, all calibration and configuration data is saved within the sensor’s smart connector, not the indicator, allowing for tru interchangeability. In addition, all sensors are fully compatible with the more basic 3i force/torque indicator.

Model 7i, Model 7i – Professional Force/Torque Indicator

The 7i professional digital force/torque indicator is designed to work with a wide range of remote force and torque sensors. Exclusive Plug & TestTM technology allows all calibration and configuration data to be saved within the sensor’s smart connector, not the indicator, allowing for true interchangeability. In addition to the 5i indicator, the 7i features high speed continuous data capture and storage, with memory for up to 5,000 readings, at an acquisition rate of up to 14,000 Hz. The 7i also features programmable footswitch sequencing, break detection, and 1st / 2nd peak detection. Coefficient of friction unit of measurement and a user-defined unit of measurement add flexibility for specialized applications. For productivity enhancement, the indicator also features automatic data output, data storage, and zeroing functions upon the completion of break detection, averaging, external trigger, and 1st / 2nd peak detection. The included MESURTM Lite data acquisition software tabulates continuous or single point data. Data saved in the indicator’s memory can also be downloaded in bulk. One-click export to Excel easily allows for further data manipulation.

MR01-100, Plug & Test (TM) Force Sensor, 100 Lbs

Series R01 rugged smart sensors are designed for measuring tension and compression force, with applications in virtually every industry. Durable S-Beam design with threaded holes on two sides allows for many configurations. Steel construction ensures many years of use. The sensor can be integrated into an existing system or mounted to a Mark-10 test stand. Capacities available from 50 to 10,000 lbF [250 N to 50 kN]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test™ technology.

MR02-1000, Plug & Test (TM) Force Sensor, 1000 Lbs

Series R02 button type smart sensors are designed for compression measurement applications in virtually every industry. Compact and rugged, Series R02 sensors are ideal for heavy duty applications with space constraints. Capacities available from 100 to 10,000 lbF [500 N to 50 kN]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test™ technology.

MR03-10, Plug & Test (TM) Force Sensor, 10 Lbs

Series R03 smart sensors are designed for tension and compression measurement applications in virtually every industry. Threaded holes on two sides can accept a variety of hooks and implements, making this sensor particularly well-suited for inline tests. Capacities available from 0.25 to 100 lbF [1 to 500 N]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) technology.

MR05-500, Plug & Test (TM) Force Sensor, 500 Lbs

Series R05 fully-enclosed smart sensors are designed for pull / push measurements. Useful in ergonomics testing, workplace safety testing, and general lifting or tension / compression requirements. Threaded holes are supplied to accommodate various mounting configurations and attachments. For up to 500 lbF [2,500 N]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) technology.

MR50-100, Plug & Test (TM) Torque Sensor, 100 LbFin

Series R50 smart sensors measure bi-directional torque for a wide variety of applications across virtually all industries. Contain a Jacobs chuck for up to 0.5 in [12.7 mm] diameter samples, bits, or fixtures. The sensors can be used as hand-held devices, or mounted to a test stand. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) techology.

MR51-100, Plug & Test (TM) Torque Sensor, 100 lbFin

Series R51 smart sensors measure bi-directional torque for numerous applications across virtually all industries. Interchangeable Jacobs chucks and bit holder add flexibility for a variety of applications. The sensors can be used as hand-held devices or mounted to a test stand. Superb overload protection adds peace of mind. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) technology.

MR52-100, Plug & Test (TM) Torque Sensor, 100 LbFin

Series R52 smart sensors measure bi-directional torque for a wide variety of applications across virtually all industries. Calibrate torque tools, or use these sensors as componenets of a torque testing system. Tapped holes on every surface allow for easy mounting to a work bench or fixture. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) technology.

MR53-100, Plug & Test (TM) Torque Sensor, 100 LbFin

Series R53 smart sensors measure bi-directional (application and removal) bottle cap torque and other applications in the food and beverage, cosmetcis, consumer products, and other insdustries. Adjustable posts accommodate a range of sample sizes, while alternative gripping attachments (high capacities only) accommodate unique shapes. Capacities available from 10 ozFin to 100 lbFin [7 to 1150 Ncm]. Compatible with Mark-10 model 5i and 3i indicators (sold separately) through unique Plug & Test (TM) technology.

MR55-100, Plug & Test (TM) Torque Sensor, 100 LbFin

This rugged series of torque sensors is ideal for a wide range of torque testing applications in numerous industries. Square drives on both ends permit inline use with a torque wrench, or for use in OEM and other applications. Capacities available from 20 to 5,000 lbFin [2 to 550 Nm]. Compatible with Mark-10 indicators (sold separately) through unique Plug & Test (TM) technology.
