Manual Test Stands

Home » Manual Test Stands

Cooper Instruments offers a wide and unique range of motorized force measurement and torque measurement test stands. Motorized stands offer a significant advantage over manual test stands by providing constant test speed. Some models can be programmed for advanced test sequences to accommodate demanding applications. Typically the test stand will require one of our electronic force gages to be integrated with the stand.

ES10, ES10 – Vertical Lever Test Stand – 100 Lbs

  • Small size
  • Low cost
  • Mounting holes for bench mounting
  • Optional 1″ (25.4 mm) dial indicator travel kit
  • Loading lever can be placed in 3 positions for ease of operation
  • Large base plate with 5 # 10-32 holes for fixture mounting

ES20, ES20 – Hand Wheel Test Stand – 100 Lb

  • Small size
  • Low cost
  • Mounting holes for bench mounting
  • Optional 1″ (25.4 mm) dial indicator travel kit
  • Large base plate with 5 # 10-32 holes for fixture mounting

ES30, ES30 – Precision Wheel Test Stand – 200 Lb

  • Modular Design: Base may be removed and the stand may be used as a component of a larger system
  • Field upgradeable to a motorized stand (ESM) by installing a motor drive kit
  • Mounting holes for bench mounting
  • Optional digital travel display
  • Low cost

SP1010A, 10 Ton Bench And Floor Presses

  • Hydraulic power choices of single speed hand pump or quarter horse® electric/hydraulic hand pump
  • Hydraulic gauges, hoses and fittings included

SPA2514, 25 Ton Open Throat & Economy Press

  • Rugged, yet reasonably priced press for those frequently performed pressing jobs
  • Lower bed adjust to desired height

TSC, TSC/TSCH – Precision Wheel Test Stand – 1000 Lbs

  • Small size
  • Mounting holes for bench mounting
  • Loading table with 25 No. 10-32 holes for fixture mounting
  • Precision ACME screw and nut
  • Optional digital travel display

TSF, TSF & TSFH Hand Wheel Operated Test Stand

  • These test stands are ruggedly built for many years of service in the laboratory and industrial environments. Used for either compression or tension their design allows for easy operation in the entire 1000 Ib load range. Modular construction provides for many nonstandard configurations including field configurable left or right handed operations. An optional digital travel display with a resolution of 0.000570.01 mm allows for precision spring testing as well as a variety of material testing tasks.
