The first high capacity load cells designed, back in the mid 50’s were what is know today as “Canister” load cells. The design consisted of double diaphragms, which were brazed in place to reduce the effects of side and angular loads. These cells were typically hermetically sealed and very durable. They usually require slide plate assemblies and stay rods to prevent the introduction of additional side loads. These load cells were typically used in motor truck scales, rail road track scales and for tank weighing. Rocker column load cells, shear beams and double ended shear beams have subsequently replaced the need for Canister load cells. Canister load cells have been widely used and there are many thousands still in use. Group Four is in the ideal position to provide replacement units when needed.

Products

View as : image image

LRCN (5038) dual bridge load cell IP67

Capacity: .25-2


Description >

The LRCN dual bridge load cell is a tension and compression design featuring two, full bridge, 3 mv/v outputs while achieving an accuracy of 0.15% full scale. Applications: Rocket Motor Testing, Break Strength Testing, Compression Test Apparatus Capacity: .25, .5, 1, 2, 2.5, 3, 5, 10, 15, 20, 2 ...
View Details >

ATC (5000) Tension/Compression Compact Load Cell

Capacity: 1, 2, 5, 10, 25, 50klbs


Description >

The ATC is a canister load cell specially designed for the measurement compressive/ tension forces and weight. Its form factor allows for better stability and use in small space applications. Capacity: 1, 2, 5, 10, 25, 50klbs
View Details >

RC (5030) Stainless Steel Rocker Column Load Cell IP69

Capacity: 5t to 50t


Description >

The type RC is a stainless steel self centering rocker column load cell with complete hermetic sealing. It is a perfect fit for use in harsh industrial environments.Capacity: 5t to 50t Output: 2±0.1% mV/V Applications: Weighbridges, hoppers, tanks and silos.
View Details >

RCH (5031) Stainless Steel Digital Rocker Column IP68

Capacity: 30klbs


Description >

The RCH is a stainless steel compression rocker column load cell is ideal for use in truck scales, tank weighing, hopper weighing, silo weighing, grain carts, gravity carts, feed mixers, fertilizer and manure spreaders. Capacity: 30klbs
View Details >

JALH (5033) Compression Canister Load Cell

Capacity: 10klb to 100klb


Description >

The JALH Multi-Column load cell is ideal for measurement of high loads. Available in capacities of 10-100 klbs. Capacity: 10klb to 100klb Applications: Aircraft weighing, tank weighing, truck scales
View Details >

COLC (5038) Tension/Compression Load Cell

Capacity: 10klb


Description >

The COLC canister load cell is designed to measure forces in tension and compression up to 10,000lbs.Capacity: 10klb Applications: Axial tension and compression
View Details >

DTC (5043D) Digital Compression Canister Load Cell

Capacity: 10k to 50k


Description >

This digital column type load cell, designed for tension and compression force testing applications.Capacity: 1k – 50k Applications: Aircraft weighing, Tank weighing, Truck scales, Digital force testers.
