HWPB (6005) Wing Aluminum Planar Beam Load Cell IP65

Capacity: 7.5kg to 100kg

The HWPB is a very low profile planar beam load cell. The load cell installation is simplified by the winged mounting arms providing optimum load cell performance in all types of scale structure.

  • Capacities from 7.5kg to 100kg
  • Aluminum construction
  • Environmental protection IP65
  • Very low profile design

  • Compact scales, bench and floor scales, retail and counting scales, special applications in medical and other areas




  • Shielded cable version
